3D plasma rotary cutting machine

Cutting Plasma Plotter 3D dimension operated by CNC with 4 axis: linear, circular interpolation and another two supplementary axis for better results. (Total : X, Y, Z, A)

• Brushless CNC drivers and motors.
• Plasma generator maximum 45A.
• Automatic or manuall adjustment of smoke extraction system following the torch.
• Automatic or manuall adjustment of the cutting torch when the diameter of the tube changes
• Automatic or manuall lathe chuck to place the tube in the machine.
• Manuall regulation to the supporting axes (the axes which they rotate the tubes) when the diameter of the tube changes.
• Diameter from 80 mm to 550 mm.
• Thickness from 0.4mm to 2.5 mm.
• Materials: steel, galvanized ,copper, aluminium.
• PC Panel (laptop) with USB port for data transfer from PC with O.S. Windows Professional 7, or Windows 11.
• Import/Export drawings by an external CAD.

CE Marks and Declaration of Conformity
In order to improve the product Metallwork Psilos reserves the right to make changes without notice.
